Not a design dashboard. A conversion: reference → product definition → tech pack → cost → sample. AI-assisted. Factory-validated.
Click a node. Idea on the left, product definition in the centre, engineering and sample-ready views on the right.
EditorialFabric $18.12 · Labor $5.38 · Trims $0.30
Shell fabric nesting
1 : 1.00 · BM-TP-214
Women
Tops
Full geometry
POM & marker ready
07 · Factory pack
POM, BOM, construction notes, graded sizes and DXF. This is what our sample room and sewing line work from. Open the breakdown below.
Style
Silk-Touch Camp Shirt
BM-TP-214 · Tops · XS–XXL
The canvas node is the summary. Below is the document our sample room actually uses — measurements, materials, construction and a graded chart, generated together.
01 · Points of measure
| Pt | Location | Spec | Tol. |
|---|---|---|---|
| A | Chest, 2.5cm below armhole | 52.0 | ±1.0 |
| B | Across shoulder | 44.0 | ±0.5 |
| C | Sleeve length from CB | 82.0 | ±1.0 |
| D | Bicep, 2.5cm below armhole | 38.0 | ±0.8 |
| E | Cuff opening, flat | 12.5 | ±0.3 |
| F | Body length from HSP | 72.0 | ±1.0 |
| G | Collar stand height | 3.2 | ±0.2 |
| H | Pocket width × height | 12.0 × 13.5 | ±0.3 |
02 · Bill of materials
Shell
100% viscose satin, 120 GSM, mill-sourced
1.65 m / pc
Interlining
Fusible collar / cuff, 40 GSM
0.18 m / pc
Buttons
Horn-look 18L, 6 pcs + 1 spare
7 pcs
Thread
Core-spun poly, colour-matched
120 m
Label set
Woven brand, size, care
1 set
03 · Construction
04 · Graded size chart
| Measure | S | M | L | XL |
|---|---|---|---|---|
| Chest | 48 | 50 | 52 | 54 |
| Shoulder | 42 | 43 | 44 | 45 |
| Sleeve CB | 80 | 81 | 82 | 83 |
| Length HSP | 70 | 71 | 72 | 73 |
05 · Callouts
Collar, pocket, cuff and hem called out on front/back flats — the same frames as the editorial node.
06 · Colorways
Ecru, Black, Sand, Custom Pantone. Lab dips before bulk; shade band on the PP sample.
07 · Files
DXF for CAD, POM spreadsheet, construction PDF, nested marker. Sent with the first sample comment sheet.
Start your product. The factory still cuts the garment.
Upload a reference or fork a library style. We return a spec the floor can sew, then a sample.
